Syveco offers the pressure gauge 1613 composed of a stainless steel case, a 1/4'' radial brass fitting, class 1.6, with glycerine, polycarbonate glass, for compressor and shipbuilding
| Specification | Value |
|---|---|
| DN inches NPS | 1/4'' |
| Construction standard | EN 837-1 |
| Brand | T-METER |
| Pressure range | -1 / 1 Bar |
| Application | Heating / Sanitary / Drinking water / Air conditioning / Irrigation |
| Dial diameter (mm) | 63 |
| Fluid | Cold water |
| Protection index (IP) | IP 65 |
| Housing material | Stainless steel |
| Connections | BSP M |
| TS max (°C) | 60 |
| TS min (°C) | 0 |
| Pressure gauge type | Glycerine pressure gauge |
| Warranty period | 2 years |
| Pressure gauge connection | Radial |
If you have any questions about this product, please feel free to contact us.
| Product Name | Product Number | EVAC Number | Price | Add to Cart |
|---|---|---|---|---|
| BSP M -1 / 1 Bar | 1613001 | S1013553 |
€7.07
(excl. btw)
|
add to cart |
| BSP M 0 / 1.6 Bar | 1613002 | S1013554 |
€7.07
(excl. btw)
|
add to cart |
| BSP M 0 / 2.5 Bar | 1613003 | S1013555 |
€7.07
(excl. btw)
|
add to cart |
| BSP M 0 / 4 Bar | 1613004 | S1013556 |
€7.07
(excl. btw)
|
add to cart |
| BSP M 0 / 6 Bar | 1613005 | S1013557 |
€7.07
(excl. btw)
|
add to cart |
| BSP M 0 / 10 Bar | 1613006 | S1013558 |
€7.07
(excl. btw)
|
add to cart |
| BSP M 0 / 16 Bar | 1613007 | S1013559 |
€7.07
(excl. btw)
|
add to cart |
| BSP M 0 / 25 Bar | 1613008 | S1013560 |
€7.07
(excl. btw)
|
add to cart |
| BSP M 0 / 40 Bar | 1613009 | S1013561 |
€7.07
(excl. btw)
|
add to cart |
| BSP M 0 / 60 Bar | 1613010 | S1013562 |
€7.07
(excl. btw)
|
add to cart |
| BSP M 0 / 100 Bar | 1613011 | S1013563 |
€7.07
(excl. btw)
|
add to cart |
| BSP M 0 / 160 Bar | 1613012 | S1013564 |
€7.07
(excl. btw)
|
add to cart |
| BSP M 0 / 250 Bar | 1613013 | S1013565 |
€7.07
(excl. btw)
|
add to cart |
| BSP M 0 / 400 Bar | 1613014 | S1013566 |
€7.07
(excl. btw)
|
add to cart |
| BSP M 0 / 600 Bar | 1613015 | S1013567 |
€7.07
(excl. btw)
|
add to cart |
